Energy management: Power blocks for electrical distribution panels

Power management: BlockMaster Electronics introduces new 255- and 380-amp power blocks for electrical distribution panels.

Content Dam Up En Articles 2017 06 Energy Management Power Blocks For Electrical Distribution Panels Leftcolumn Article Thumbnailimage File

Energy management: BlockMaster Electronics, a supplier of terminal blocks for electrical and electronic distribution, announces the introduction of their new HP Series High Power Terminal Blocks. The new power blocks are rated 600 volt with a choice of 255 or 380 amps, for electrical applications in power panel distribution. The new HP Series High Power Terminal Blocks can also be used for lighter power applications, and therefore has extended utility as a “one size fits all” product line.

The new HP Series line of Terminal Blocks are ideally suited for high power distribution in electrical panels, to transition larger wire gauge, high power mains to smaller gauge lower power branch circuits, in applications such as:

• HVAC equipment
• Standby Generators
• Chillers
• Switch Gear
• Lighting Panels
• Other Industrial & Commercial Applications

BlockMaster’s new HP Series High Power Terminal Blocks consists of five products, with a selection of 1, 2 or 3 poles, optional clear plastic covers, and a wide variety of terminations, including:

LINE SIDE LOAD SIDE

Screw clamp Stud

Screw clamp Screws

Screw clamp Screw clamp

Stud Stud

Stud Screws

All HP Series High Power Terminal Blocks comply with UL and CSA Standards, as well as RoHS, and include the following features:

• Rated: 600 Volts, 255 or 380 Amps
• Operating Temperature: -25° C to +125° C.
• Housing: Phenolic 94V-0
• Cover: Polycarbonate (UL94V-2)
• Terminals: Aluminum
• Withstanding Voltage: AC 2,500 V

About BlockMaster Electronics, Inc.
BlockMaster Electronics has provided innovative interconnect and terminal block solutions to electrical and electronic OEMs since 1994. The company has low-cost, high-quality manufacturing capabilities and can provide reliable products from stock.

A distinct competitive advantage that BlockMaster offers its customers includes the ability to make modifications in-house to its terminal blocks based on customer requirements. BlockMaster’s Value-added Center provides the ability to fabricate, modify and print legends on our blocks at our Illinois facility for quick turnaround.

BlockMaster Electronics manufactures terminal blocks from 1 to 400 amps, including PCB styles up to 130 amps. The company offers over 9,500 P/Ns including PCB, Feed-through and Power Distribution types. BlockMaster’s Value-added Center can also provide quick turn around on prototypes.
