Work light: Heavy duty trailer mounted light tower

Utility equipment: The LM-20-3S-TLR Trailer Mounted Light Tower from Larson Electronics is a 20-foot extendable light tower that can be equipped with high output LED, HID, Halogen, or Metal Halide light fixtures.

Oct 4th, 2013
Content Dam Up En Articles 2013 10 Work Light Heavy Duty Trailer Mounted Light Tower Leftcolumn Article Thumbnailimage File

Safety lighting: The LM-20-3S-TLR Trailer Mounted Light Tower from Larson Electronics is a 20 foot extendable light tower that can be equipped with high output LED, HID, Halogen, or Metal Halide light fixtures. This tower includeds a rotating base which allows the operators to aim the lights in any direction regardless of tower location.


The LM-20-3S-TLR trainler mounted telescoping steel light tower allows operators to quickly and safely deploy illumination in locations where elevated illumination is needed for maximum area coverage. This five section light boom can be extended to 20 feet for maximum area coverage and collapsed to 9.5 feet and folded over for transport or when not in use. The tower is constructed of square steel tubing with five sections of 9 feet, 7 feet, and 4 feet. The mast is elevated from the fold down position using an included 1,000 lb hand winch with 3/16 inch aircraft cable, and extended to its full height using a second 1,000 lbs winch. A rotating mounting platform allows operators to rotate the entire tower on its base, providing an easy means of directing the lights regardless of tower location.

This light mast is mounted to a 11 foot by 4 foot, single axle trailer. Constructed of 2" by 3" square tubing, this trailer can be mounted on any 2" ball type receiver hitch. This trailer is equipped with a 4-pin flat plug for the tail lights. This light mast trailer is features a receiving bracket to secure the foldered light mast during transit. A 24 inch wide and 1/4 inch thick mounting plate attaches the upper section of the mast to this single axle trailer, which provides a strong and stable platform for the four metal halide fixtures. This base-plate mount also includes a rotating axis which allows the entire tower to be rotated in both the folded down position and upright position. A support bar mounted towards the rear of the trailer holds the mast in place for secure transportation and storage.

This light tower when lowered to 9.5 feet can withstand winds up to 125 mph. We can equip this mast with 1000W or 1500W Metal Halide lights or a wide variety of high powered LED lights with comparable power. We also offer a choice of either the manual 1,000 lbs hand winches included standard or optional electric winches.
