Power measurement: Testing software is fast, safe, more efficient

Test and measurement equipment: OMICRON’s Primary Test Manager (PTM) software supports you during diagnostic testing of power transformers, circuit breakers, current transformers and associated equipment like bushings and tap changers.

Content Dam Up En Articles 2014 04 Power Measurement Testing Software Is Fast Safe More Efficient Leftcolumn Article Thumbnailimage File

Power transformer testing: The Primary Test Manager (PTM) software supports you during diagnostic testing of power transformers, circuit breakers, current transformers and associated equipment like bushings and tap changers. PTM was first to automate the creation of asset-specific, guided test plans together with dynamic test connection diagrams based on user identification and matching of nameplate parameters like ratings and vector diagrams. And because PTM is the interface software that drives OMICRON’s multifunctional test system CPC100 + CP TD1, PTM provides this exceptional guidance for a wide range of diagnostic tests according to the latest industry standards and guidelines. Due to an integrated high-performance database, electrical assets and the associated test plans can be managed easily.

These are the features that make PTM the leader to follow:
• Test Connection Diagrams
• Guided Test Procedures
• Graphical and Tabular Test Results
• Auto-Assessment of Test Results
• Custom Reporting

In combination with OMICRON’s CPC100 + CP TD1 test system, PTM covers all of the traditional tests such as Power Factor, Exciting Current, Leakage Reactance, Turns Ratio, and DC Winding Resistance and generates one single report including all items. Due to its unique capabilities, the test system features a range of additional advanced tests which increase the diagnostic reach of the traditional tests and can be included in the test plan:
• Variable Frequency Power Factor (15 Hz to 400 Hz)
• Frequency Response of Stray Losses (FRSL)
• Dynamic Winding Resistance (Slope & Ripple)

OMICRON’s world-class development team, leveraging on their original roots in software development and integrating their vast knowledge in the operation and assessment of power apparatus, has equipped the latest version with a set of new features that will make PTM even more exciting for you:
• Extended Auto-Assessment for Power Transformers and Bushings
• Easily compare multiple Test Results in a single View
• DEMAG your Transformer using a new Test in PTM + CPC 100
• Automated Turns Ratio Test for Phase-shifting Transformers
• Now compatible with Windows 8 & 8.1 Operating Systems
