Top Brake Manufacturers Design for Noise, Vibration and Harshness Control
Elimination of noise, vibration and harshness is critical to a comfortable, safe ride.
By Ron Sherman
Brake technology is one of the greatest contributors to the presence of noise, vibration and harshness (NVH) in vehicles; however, top-quality brake technology can successfully control NVH to give a safer, more comfortable ride. Friction formulations and shim technology are particularly critical to automotive NVH control, as is getting a complete brake job, including rotor replacement or resurfacing, each time pads or other brake components are replaced.
Noise, Vibration and Harshness in Brake Technology
The term NVH came into popular use in the automotive brake industry some 20 years ago. At that time, friction formulations and other aspects of brake design were changing in response to issues of rotor pulsation and significant premature rotor wear. Older friction materials caused rotors to wear out prematurely, which in turn caused vibration that could be felt by drivers. Around this time, OE brake manufacturers also decided to make rotors thinner to save on material costs.
Rotors feature fins between inner and outer plate layers. The plates on the outside of the fins get worn down little by little while braking, and the fins expand and contract based on the heat generated by braking friction. As a result, the plates wear evenly at the high temperatures caused by braking, but once the brakes cool back down and the fins contract, the rotor surface becomes uneven, with small peaks and valleys apparent at ambient temperatures. When brakes are still cold - for instance, when a driver has just started the car, before the brakes have generated enough friction to warm up - the uneven surface of the rotors comes into contact with the flat brake pads, which can cause the front end, steering, and/or brake pedal to vibrate and sometimes generate noise. This accounts for brake noise that is primarily noticeable when first starting a car. A visual inspection of rotors worn in this way that are causing vibration will often show scoring.
Once rotor design was changed to be thinner, friction formulations needed to be changed as well because the highly abrasive formulations of the past would cause even more vibration with thinner rotors that wear out more quickly. New friction materials were developed that are softer and work in conjunction with rotor design to minimize vibration and noise. NVH control is at the forefront of modern automotive brake design as brake manufacturers strive to provide customers with the quiet, comfortable ride performance they expect.
Though heavy vibration can affect brake safety, as it can affect steering stability particularly while turning, noise elimination is of greatest concern for automotive brake manufacturers. Drivers expect brakes to operate quietly and can be distracted or frustrated by noisy, vibration-prone brakes.
Top Brake Manufacturers Design for NVH Control
Two components aid in the control of NVH for braking: the friction material and the shims, which are small rubber or adhesive components that fit between other brake components (notably, the pads and rotors) to reduce noise and vibration. Friction materials work in conjunction with rotor design to minimize vibration and noise by damping vibration and noise harmonics. Shims also aid in noise and vibration damping, and their design and formulation can be as advanced as that of the friction materials. Friction formulations are proprietary and unique to each brake manufacturer, so it is important to purchase brake products from reputable manufacturers if NVH control is a priority.
Take, for example, Bendix Brakes. Unlike most automotive brake manufacturers, GRI Engineering & Development Inc. (GRIE) manufactures all of the components for the Bendix Brakes brand of automotive brakes, including shims. While other companies are driven by cost and availability in the marketplace when purchasing shim technology, GRIE is able to focus primarily on designing and manufacturing shims that use high quality shim materials to eliminate the noise and vibration frequencies generated by braking. In addition, the company delivers friction technology that is proven to meet or exceed OEM specifications and customer expectations.
Ultimately, every part of the braking system works together to eliminate NVH effects: calipers, caliper hardware, backing plates, rotors, shims and friction formulations. Automotive brake manufacturers such as GRIE, which has a long history of working with all of these components together rather than manufacturing just a single component of the system, are more able to ensure all the parts of the brake system work together to eliminate noise and vibration from braking.
Just as manufacturers who work with every part of the brake system are more capable of managing NVH, performing a complete brake job is also key to controlling noise and vibration. Even if replacing brake pads with pads that have been expertly engineered for quiet performance, if rotors or shims are worn down, noise and vibration can occur.
This means that when changing brake pads, rotors should either be replaced as well, or, if the rotors are still within specifications, should be thoroughly cleaned and resurfaced. The caliper and caliper hardware, piston, seals and other components should be checked to ensure they are all working properly and are adequately lubricated. Opting for a complete brake job when it is time to service brakes is the best way to ensure all components will work together for noise-free braking. Attempting to cut costs by not replacing or resurfacing rotors will almost certainly lead to noisy, uncomfortable braking.
To conclude, automotive brake technology has come a long way over the past two decades in the control of NVH. Industry-leading manufacturers create top-of-the-line friction formulations and shim technology that work together to damp the frequencies of sound and vibration caused by braking. Relying on these manufacturers, as well as ensuring a comprehensive brake service includes a complete brake job, will help to virtually eliminate noise, vibration and harshness from your braking experience.
Ron Sherman is with GRI Engineering & Development Inc.
