Safety lighting: Explosion proof signal light with an audible horn
Safety equipment: Larson Electronics has released a new single colored explosion proof signal light with an audible horn. The EPL-TL-1X10W-C-PA LED signal light is a Class 1 Division 1 and Class 2 Division 1 LED signal light equipped with an audible horn and approved for use in hazardous environments.
Safety products: Larson Electronics has released a new single colored explosion proof signal light with an audible horn. The EPL-TL-1X10W-C-PA LED signal light is a Class 1 Division 1 and Class 2 Division 1 LED signal light equipped with an audible horn and approved for use in hazardous environments where explosive and flammable gases, vapors, and dusts exist or stand the potential to exist.
This explosion proof signal stack light is designed for routing traffic in industrial refueling stations and processing status indications in manufacturing facilities. This signal light is equipped with a single 10 watt LED lamp that produces an optional color output of red, blue, green, amber, purple, or white. This light can be configured to operate on a steady burn or strobe and each LED lamp offers an exceptional 1,050 lumen output. The explosion proof audible alarm setup sounds a unique tone per the user setting. Multiple units can be configured for different lamp colors and different tones, providing operators in hazardous locations with an effective and powerful alert system that can withstand demanding conditions and be heard over the operation of industrial machinery and equipment.
Wiring is made through a 3/4” NPT conduit access hub and can be configured to work on 120 or 240 volts AC for use with standard line voltages or 24 volts DC for low voltage operation. A NEMA 4X rated explosion proof junction box protects the internal wiring and can be tapped in order to connect this signal light to power sources. Mounting is provided by a heavy gauge aluminum base with predrilled holes designed to be bolted to walls and flat surfaces for permanent and secure attachment. Power is provided by individual conductors to allow independent operation of each lamp and tone combination. Operators can tap the C1D1 junction box in order to connect to a power source. This unit carries a T3 temperature rating, is weatherproof, dust-proof, NEMA 4X rated and marine rated for wet environments.
“The powerful audible horn reaches a peak at 110dBA, producing a sound that can be easily heard over industrial machinery and equipment,” said Rob Bresnahan, CEO of Larson Electronics. “These units can be customized with different colors as well as the number of lights and horns needed. Call us with your requirements today.”
Larson Electronics carries an extensive line of LED light towers, portable power distribution systems, explosion proof lights, portable work lights and industrial grade LED area lights.
