Utility supplies: Two-component epoxy system provides electrical, thermal conductivity

Electrical tools: Master Bond’s flexible two-component epoxy system features electrical and thermal conductivity.

Content Dam Up En Articles 2013 11 Utility Supplies Two Component Epoxy System Provides Electrical Thermal Conductivity Leftcolumn Article Thumbnailimage File

Utility supplies: Formulated with a silver coated nickel filler, Master Bond EP79FL is a two part, electrically conductive epoxy for bonding, sealing and coating applications. It has low volume resistivity of less than 0.005 ohm-cm and is suitable for a variety of uses in the electronic, aerospace, computer, semiconductor and electro-optic industries.

In addition to its electrical properties, this system is very flexible upon curing, enabling it to be used in applications involving thermal cycling as well as thermal and mechanical shocks. It adheres well to metals, composites, glass, ceramics, vulcanized rubbers and many plastics while offering a T-peel strength that exceeds 25 pli. EP79FL is serviceable over the wide temperature range of 4K to +275°F allowing it to be used in cryogenic environments. Also, this epoxy is a reliable thermal conductor.

EP79FL has a convenient one to one mix ratio by weight, and it cures readily at room temperature or more rapidly at elevated temperatures. It can be applied with minimal sagging or dripping, even on vertical surfaces. It can be made thinner and flowable by adding 5-10% by weight of an appropriate solvent such as xylene, acetone or MEK.

This epoxy is available in syringes, glass jars or in premixed and frozen syringes. The syringes have a shelf life of 3 months, while the jars have a shelf life of 6 months when stored at room temperature in its original, unopened packaging.

Master Bond Electrically Conductive Adhesives, Sealants and Coatings

Master Bond EP79FL is a flexible, heat dissipative, silver coated nickel filled epoxy that can be considered a cost effective alternative to more standard silver conductive epoxies. This two part system offers cryogenic serviceability, high peel strength and resistance to thermal cycling.

For more information about Master Bond or other products, click here to go to Utility Products’ Buyers Guide.
