High frequency probe station test cables

MegaPhase, a manufacturer of high performance RF coaxial cables and connectors for advanced microwave and optical electronic systems, has announced the release of a new line of high-frequency probe station test cables—the MegaPhase PS Series.

Content Dam Up Online Articles 2012 07 Megaphase

Stroudsburg, Pa.—MegaPhase, a manufacturer of high performance RF coaxial cables and connectors for advanced microwave and optical electronic systems, has announced the release of a new line of high-frequency probe station test cables, the MegaPhase PS Series.

The PS Series test cables are specifically designed for dynamic probe station measurements and offer low loss, phase stable performance through 70 GHz. The PS Series cable can be mechanically formed to ensure proper connector-to-connector spacing and that interfering surfaces associated with a given probe can be avoided while ensuring the station head has complete freedom of movement. MegaPhase offers a variety of industry standard high performance connectors including: 1.85 mm, 2.4 mm, 2.92mm, 3.5 mm and SMA for compatibility with current probe station configurations. The cables are sold as both OEM components or as replacement cables for existing probe stations.

MegaPhase has employed their rugged RF technology to provide a low-profile form factor meeting the tight constraints associated with precision wafer measurements. The PS assemblies provide repeatable and reliable measurements with excellent phase and amplitude stability, minimum attenuation, high shielding effectiveness and low VSWR.

The PS Series probe station cables include the following benefits:

1. Phase/amplitude stable for greater measurement accuracy
2. Low VSWR : better than 1.45:1 at 40 GHz and 50 GHz; 1.50:1 at 67 GHz
3. Insertion loss: better than 4.26dB at 40 GHz; 6.00dB at 50 GHz; 6.85 dB at 67 GHz
4. Shielding effectiveness: greater than 90 dB per MIL-STD 1344, Method 3008
5. Connectors
• 26.5 GHz; Precision SMA
• 34 GHz; 3.5 mm connector- intermateable with SMA, 2.9-mm interfaces
• 40 GHz; 2.92-mm ("K" type) - intermateable with SMA, 3.5-mm interfaces
• 50 GHz; 2.4-mm - intermateable with 2.4-mm and 1.85-mm interfaces
• 67 GHz; 1.85-mm - intermateable with 2.4-mm and 1.85-mm interfaces
6. Custom lengths available upon request for all frequencies
