Work light: Skid mount five stage light mast
Safety lighting: Larson Electronics’ LM-SMDE-24-8-5S-EW-RD-SLHL-AH skid mount electric light tower with articulating mast head provides a safe and effective way for operators to quickly deploy user provided lights, heat lamps, and equipment to elevations up to 25 feet.
Work light: The Larson Electronics LM-SMDE-24-8-5S-EW-RD-SLHL-AH skid mount electric light tower with articulating mast head provides a safe and effective way for operators to quickly deploy user provided lights, heat lamps, and equipment to elevations up to twenty-five feet. The light tower features a rotating boom that allows for 360° of rotation, an articulating mast head providing up to 180° degrees of tilt, an electric winch for easy deployment, and is mounted to a cube frame with skid pockets and 4-corner pick eyes for easy transportation. Each assembly is equipped with 50' of 10/3 SOOW cable and terminated in a 30A cord cap.
The LM-SMDE-24-8-5S-EW-RD-SLHL-AH five stage telescoping steel light mast with electric winch from Larson Electronics’ is designed to quickly and safely deploy lights, cameras, heat lamps, or other electrical equipment in locations where elevated illumination is needed for maximum area coverage. This light boom can be extended to 25.5' for maximum area coverage and collapsed to 9.25' for applications where a footprint smaller is required. The tower is constructed of square steel tubing with a base section 5.92' in length and 7" by 7" by 1/4" thick, a lower section 6.04' in length and 5" by 5" by 3/16" thick, a middle section 6.19' in length and 4" by 4" by 1/8" thick, an upper section 6.34' in length and 3" by 3" by 1/8" thick, and a top section 6.5' in length and 2" by 2" by 1/8" thick. Each section has a 1' overlap. The mast is elevated using an included 2,500 lbs. electric winch with 3/16" aircraft grade galvanized steel cable.
