Test equipment: Test stability of microgrids, distribution grids, back-up power systems

Test products: Power Standards Lab unveiled Grid Thumper at DistribuTECH: patent-pending system actively tests grid stability.

Content Dam Up En Articles 2018 02 Test Equipment Test Stability Of Microgrids Distribution Grids Back Up Power Systems Leftcolumn Article Thumbnailimage File

Test equipment: Power Standards Lab Inc. (PSL), a provider of grid instruments, has announced Grid Thumper™, a breakthrough solution for testing the stability of microgrids, distribution grids, and back-up power systems.

When subjected to stand-alone certification testing, individual pieces of grid equipment (generators, inverters, UPS, transfer switches, etc.) almost always operate correctly. When they’re connected together as a system, exactly how their control loops will interact is unknown.

Grid Thumper rigorously tests complete, connected systems, including active distribution grids, detecting harmful instabilities that would otherwise be invisible. It uses patent-pending technology to briefly connect large, time-synchronized resistive and reactive loads – up to a megawatt, often for a tiny fraction of a second – then ultra-precise PSL PQube 3 and microPMU sensors record the grid’s system response.

Grid operators, data centers, hospitals, military bases, sports and entertainment venues, can all gain peace of mind that their critical power systems will perform as expected when needed most.

“Our company designs and integrates fail-safe power solutions for the defense and broadcast industries,” said Bill Wenzlau, CEO of Wenzlau Engineering. “With Grid Thumper, we are able to test sophisticated power scenarios to validate system reliability and availability. We can now provide the military with objective evidence that tactical radars will identify threats, and assure national television networks that major sporting events will remain on-air. Through our partnership with PSL, Wenzlau Engineering and our customers operate with a heightened sense of confidence.”

Researchers at U.S. National Labs have already shown interest in using Grid Thumper to examine PV system stability and detect sophisticated grid cyberattacks. Military suppliers, hospitals and data centers will rely on the non-disruptive Grid Thumper stability tests on mission-critical live grids. Utilities are discussing how to use Grid Thumper to map out distribution grids, and even to increase the amount of Distributed Energy Resources (DERs), such as solar PV, that is permitted on a given distribution line. Operators of island grids have plans to use Grid Thumper to measure actual control loop response and damping in a large population of installed inverters.

“It’s difficult to characterize in steady-state, so let’s perturb and observe. For the semiconductor industry, PSL has a long history of precisely disturbing power, then using it to test high-value sensitive loads,” said Mario Barbaresso, President and CEO of Power Survey, parent company of Power Standards Lab. “At last, with Grid Thumper, the power industry can also take advantage of this approach. Information from non-disruptive intentional disturbances, measured with our ultra-precise instruments, will improve grid stability.”

About Power Standards Lab, Inc.
Power Standards Lab Inc. (PSL), a subsidiary of Power Survey and Equipment Ltd., is a global leader in the design and manufacture of easy-to-install, ultra-precise electric power instruments for monitoring power quality and energy, and performing data analysis. PSL partners with Fortune 500 companies in the power and energy, transportation, medical, semiconductor, telecom, and manufacturing industries, as well as government agencies, to help diagnose and solve electric power problems, provide power quality testing, and certification. PSL employees speak over 15 languages, providing localized support to customers in 58 countries.
