VIDEO: Georgia Power upgrades transmission switchgear at Plant Vogtle nuclear plant
Georgia Power transmission linemen work on the new 500- kV transmission structures that will support Vogtle Unit 4
Georgia Power recently completed the redesign of the existing 500 kV switchyard for Plant Vogtle units 1 and 2. The 500 kV switchyard takes energy from the plant and feeds it onto the power grid to serve customers across the state.
The 500 kV redesign included the addition of four new breakers, associated disconnect switches and a new relay protection scheme. The work, completed with no interruption of power distribution, will help ensure seamless integration of the new units into the overall Plant Vogtle system.
Other major transmission milestones achieved at the plant recently include the completion of in-ground work for the Unit 4 Switchyard (foundations, control conduits and cableway), the rerouting of the West McIntosh 500 kV line, the reconfiguration of the existing 230 kV switchyard and commissioning of the new Vogtle 230 kV switching station. Work continues on the Thomson-Vogtle 500 kV transmission line which is 55 miles long and runs from Thomson, Ga. to Plant Vogtle.
In addition to the transmission infrastructure taking shape, other recent construction highlights at the site include the concrete placement for the Unit 3 Annex Building basemat, the completion of the last of 12 separate water boxes within the Unit 3 Turbine Island and the arrival of multiple pieces of major equipment onsite such as the pressurizer for Unit 4.
Once Units 3 and 4 join the existing two Vogtle units already in operation, Plant Vogtle is expected to generate more electricity than any U.S. nuclear facility, enough to power more than one million homes and businesses.
