Ameren unveils advanced distributed energy microgrid
Ameren built the microgrid facility to test monitoring and control methods for aggregating clean, renewable energy sources
Ameren Corp. has completed an advanced utility-scale microgrid. The $5 million facility, located at Ameren's Technology Applications Center (TAC) adjacent to the University of Illinois campus in Champaign, Illinois, is capable of serving paying customer loads on a utility distribution feeder.
As larger companies and high energy users seek to become more energy independent, Ameren built the microgrid facility to test monitoring and control methods for aggregating clean, renewable energy sources – wind, solar, and natural gas – with advanced automation and battery storage.
The Ameren microgrid operates at utility-scale voltages, between 4 kV and 34.5 kV, with multiple levels of control. It is capable of seamlessly transitioning the power source for an entire distribution circuit from distributed generation sources to the traditional grid.
This concept, known as islanding, enables Ameren to deliver more than 1 MW to paying customers without experiencing an outage.
"Integrating microgrids onto our system can provide cleaner energy and a stronger, smarter grid capable of delivering the products and services to fit the needs of our future customers and the communities we serve," said Warner Baxter, chairman, president and CEO of Ameren Corp. "There is no better time than now to innovate and position Ameren for even better results in the years ahead."
The Ameren microgrid can produce up to 1,475 kW, enough to power more than 190 homes. The leased generation assets located on site include:
• Northern Power Systems Wind Turbine – 100 kW
• Yingli Solar Array – 125 kW
• Caterpillar Natural Gas Generator – 1,000 kW
• S&C Electric Co. Battery Storage – 250 kW
"Our focus on building a next generation energy delivery system has enabled Illinois to emerge as a national leader in smart grid innovation," said Richard J. Mark, Chairman and President of Ameren Illinois. "As the technologies we are testing at this microgrid facility become more accessible in the future, our customers will be able to count on Ameren Illinois to help them safely install and cost-effectively operate distributed generation resources.”
The microgrid is a key element of Ameren's investment in developing a smarter energy infrastructure. Along with the microgrid advancements, Ameren Illinois has added new equipment and technology to reduce outages and improve overall reliability. This summer, Ameren Illinois will begin installing 83,000 smart meters at customer locations in Champaign County. These advanced, two-way devices will provide Ameren Illinois customers with energy use data and easy access to programs to reduce energy and save money.
Construction on the Ameren microgrid was completed in December 2016, followed by testing in the first quarter of 2017.
